18
1. Turn the main power on at the main circuit breaker.
2. Make sure the spray arms and the scrap screens are in place.
3. Turn the water supply on.
4. Close the dishwasher hood.
5. Turn the wash cycle selector switch to the desired standard setting of 1 or 1.5 minutes.
6. Push the dishwasher Power Switch to the ON position. The power switch will illuminate
and the machine will ll with water.
7. Check the pressure gauge as the machine lls and make
sure the incoming water owing pressure is between 20-22 psi.
Operation
Follow the instructions below to operate the dishwasher in a Standard Wash Cycle. A Rinse
Sentry feature holds the dishwasher in a wash cycle if the booster heater temperature is below
180ºF/82ºC.
Standard Wash Cycle Operation
10
0
30
20
PSI
60
50
40
I
I
O
I
Standard 1 minute Setting
Standard 1.5 minute Setting
! VERY IMPORTANT !
THE STANDARD CYCLE
MAY BE SELECTED
BEFORE OR AFTER
THE POWER SWITCH
IS PRESSED; BUT, THE
CYCLE SELECTOR
SWITCH WILL NOT
CHANGE THE CYCLE
FROM 1 MINUTE TO 1.5
MINUTES OR VICE VERSA
WHILE THE DISHWASHER
IS ALREADY IN CYCLE.
