41
Item Part Description Qty.
No. No.
1 419002 HOSE ASSY. 1/2" ID, X 16" LG. FLARE JIC 1
2 115101 COUPLING, MALE 1/2" NPT X 1/2" 37° FLARE BRASS 2
3 100171 BUSHING, REDUCING FACE 3/4" NPT X 1/2" NPT BRASS 2
4 102438 ELBOW, STREET 1/2" NPT X 90° BRASS 1
5 0509042 BOOSTER TANK, WELDED ASSEMBLY 1
6 108954 NUT, GRIP, 6-32 W/NYLON INSERT SST 2
7 110562 THERMOSTAT, FIXED, SNAP, 240ºF 1
8 100210 PLUG, 1/8" NPT SQ. HEAD, SST 1
9 109985 SEAL, ELECTRIC HEATER FLANGE 1
For Standard Model and Direct Vent Option Model
10 111233 HEATER, 7.5KW/10KW, 208/240V/60/1PH & 3PH 1
--- 108579 HEATER, 9KW, 480V/60/3PH 1
For Condensate Removal Option Model Only
10 111232 HEATER, 10KW, 208/240V/60/1PH & 3PH 1
--- 111234 HEATER, 10KW, 480V/60/3PH 1
11 106482 WASHER, LOCK 1/4" SPLIT SST 6
12 100003 NUT, PLAIN, 1/4-20 SST 6
13 107908 COVER, HEATER 1
14 111488 JUMPER, STRIP HEATER 1
15 109069 THERMOSTAT W/CAPILLARY, 110-195ºF 1
Booster Assembly - All Models and Options
