45
Item Part Description Qty.
No. No.
Control Cabinet and Input Terminal Block Assembly
1 334232 INNER PANEL, CONTROL CABINET 1
2 107964 BUSHING, SNAP 7/8" D-FLAT 3
3 B500355 CONNECTOR, STRAIN RELIEF, CORD 1/2" 1
4 103310 GROUND LUG 2
5 100095 SCREW, ROUND HEAD, 10-32 X 3/8" SST 10
6 100100 SCREW, ROUND HEAD, 8-32 X 1/4" SST 4
7 114898 TRANSFORMER, 120:24V, 50/60HZ, 20VA 1
8 113314 TIMER, 600 SEC. INT., 110VAC 1
9 100211 SCREW, TRUSS HEAD, 10-32 X 1" SST 1
10 114947 SCREW, 6-32 X 5/8" SLOTTED PAN HEAD, SST 4
11 114470 TIMER BOARD 1
12 111036 SOCKET, RELAY 3
13 111068 RELAY, 2-POLE 10A, 120VAC 3
14 114521 END COVER, SINGLE TERMINAL, D-MZB 1.5-NS35 1
15 114520 TERMINAL, SINGLE, MZB 1.5-NS35 4
16 114760 LABEL, DETERGENT/RINSE-AID/VENT FAN 1
17 100294 TERMINAL BLOCK, 6-POLE 1
18 108122 CONTACTOR, 12A, 3-POLE 1
19 113161 STARTER, MTR. OVERLOAD, 208-230V/60/1, 9.0-14.0A 1
--- 113161 STARTER, MTR. OVERLOAD, 208-230V/60/3, 9.0-14.0A 1
--- 111627 STARTER, MTR. OVERLOAD, 440-480V/60/3, 2.5-4.0A 1
Prior to S/N D120710098
--- 111629 STARTER, MTR. OVERLOAD, 440-480V/60/3, 6.0-10.0A 1
Beginning with S/N D120710098 and above
20 111702 CONTACTOR, 50RA, 3-POLE, 120VAC COIL 2
21 107289 FUSE, 2.5A, 600V, TIME DELAY 2
22 114933 BLOCK, FUSE XFRMR 150VA 1
23 108397 XFRMR, INPUT 150VA, MV:120V 1
24 111833 BLOCK, INPUT TERMINAL. 175A, 3-POLE, 600V 1
--- 114508 CABLE ASSY., 4-CONDUCTOR (Not Shown) 1
THERMISTOR TO DISPLAY CONNECT
--- 114927 HARNESS ASSY., 10-CONDUCTOR (Not Shown) 1
CONTROL BOARD TO DISPLAY CONNECT
