53
Item Part Description Qty.
No. No.
Wash Tank Heat, Drain, Screens, and Hoses
1 109034 GASKET, 1/2" PLUG 1
2 108417 NUT, 1/2" NPT PLASTIC 1
3 108418 PLUG, 1/2" NPT PLASTIC 1
4 114386 WASHER, RUBBER 13/16" X 1-1/4" X 1/8" 1
5 333021 SCREEN, PUMP SUCTION 1
6 332544 SUPPORT, FILLER SCREEN 1
7 305164 SCREEN, SCRAP 2
8 111092 SWITCH, FLOAT 1
9 107089 NUT, JAM, 1/2-13 1
10 104882 WASHER, FLAT 2
11 107589 WASHER, LOCK, 1/2" SPLIT SST 1
12 114178 ELEMENT, HEATER 5.2 kW, 208-240-380/60/1-3, 90º 1
--- 114179 ELEMENT, HEATER 5.2 kW, 480/60/3, 90º 1
13 201029 LOCKNUT, 1/2" NPT NP 2
14 201041 WASHER, SPACER 7/8"X 1-3/16" X 1/8" 2
15 114471 VALVE, DRAIN, ELECTRIC W/COVER 1
16 104165 CLAMP, HOSE M40 SST W/CS SCREW 2
17 205990 HOSE, DRAIN 2" ID X 1-9/16" LG. 1
18 107340 CLAMP, HOSE M28 SST W/CS SCREW 4
19 114472 HOSE, OVERFLOW, 90º 1
20 107967 NUT, GRIP 1/4-20 SST W/NYLON INSERT 1
21 106026 WASHER, FLAT 1/4-20 SST 1
22 304816 STRAINER, DRAIN, 6" DIA. 1
23 104203 CLAMP, HOSE M52 SST W/CS SCREW 2
24 114467 HOSE, SUCTION 1
25 115159 HOSE, DISCHARGE 1
26 100740 BOLT, HEX 5/16-18 X 1" SST 4
27 102376 WASHER, FLAT 5/16" SST 4
28 108345 GASKET, ELEMENT, 3" X 3" X 1/8" X 2" HOLE 1
29 106013 WASHER, LOCK SPLIT, 5/16" SST 4
30 100154 NUT, PLAIN, 5/16-18 SST 4
31 111488 JUMPER, STRIP (spare for conversion) 3
32 100097 SCREW, TRUSS HD., 10-32 X 1/2" SST 6
33 107966 NUT, GRIP, 10-32 X 1/2" SST 6
34 322076 BRACKET, DUAL THERMOSTAT MOUNTING 3
35 113271 SUPPRESSOR,ARC,.01µF,47Ω 2
36 109069 THERMOSTAT, CONTROL 110-195ºF 2
37 110561 THERMOSTAT, FIXED HI-LIMIT 240ºF, (WASH TANK) 1
38 334231 BRACKET, SUPPORT THERMOSTAT 1
39 113721 SAFETY SWITCH, REED 1
40 108954 NUT, GRIP, 6-32 SST W/NYLON INSERT 2
--- 113937 MAGNET, SAFETY SWITCH (NOT SHOWN) 1
To Next Page
