Char-Broil 463211513 - Assembly Instructions; Leg Assembly and Bottom Shelf

17
ASSEMBLY
1
2
CAUTION: When unpacking grill components, two people should raise grill head from the shipping box.
ASSEMBLY
Take the leg assembly out from the shipping box, place it as shown.
Place bottom shelf to bottom shelf brace.
Tighten the pre-installed screws to bottom shelf.
Bottom Shelf
Right Leg Assembly
Left Leg Assembly
Rear
Front
