21
8
9
Grill Head
Place right side shelf to the right side of firebox.
Tighten the pre-installed screws to the right side shelf.
This step requires two people to lift and position grill head onto cart.
Carefully lower the grill head onto the cart. Make sure the regulator is placed between grease tray and front panel.
Slide the grill head back until the pre-installed screws fit completely into the slots of cart brackets. Tighten the pre-installed screws to
the fire box.
Regulator
Grease Tray
Front Panel
Pre-installed
Screw
Cart Bracket
Right Side Shelf
Tighten the pre-installed
screws
To Next Page
