RT115 Tier 3- REEL WINDER ATTACHMENT
SETUP
112 RT115 Tier 3 - REEL WINDER ATTACHMENT
SETUP
4. Remove lever arm (3).
While supporting lever arm,
remove bolt (1) that attaches
hydraulic lift cylinder to lever
arm.
For 2’ to 5’ (61 to152 cm)
diameter reels:
Rotate lever arm (3) back and
attach cylinder rod to bottom
cylinder mounting hole (1).
For 5’ to 7’ (152 to 213 cm) diameter reels:
Rotate lever arm (3) back and attach cylinder rod to top
cylinder mounting hole (2).
4. Remove lever arm (3).
While supporting lever arm,
remove bolt (1) that attaches
hydraulic lift cylinder to lever
arm.
For 2’ to 5’ (61 to152 cm)
diameter reels:
Rotate lever arm (3) back and
attach cylinder rod to bottom
cylinder mounting hole (1).
For 5’ to 7’ (152 to 213 cm) diameter reels:
Rotate lever arm (3) back and attach cylinder rod to top
cylinder mounting hole (2).
