Charles RT115 Tier 3 - SEAT ADJUSTMENT DESCRIPTIONS

RT115 Tier 3 - CONTROLS 39
SEAT ADJUSTMENT DESCRIPTIONS
RT115 Tier 3 - CONTROLS 39
SEAT ADJUSTMENT DESCRIPTIONS
SEAT ADJUSTMENT DESCRIPTIONS
Seat Slide Control
This control slides operator’s seat forward or backward.
Armrest Adjustment Control
These controls raise and lower armrests.
To adjust:
• Remove knob.
• Adjust armrest to desired position.
• Replace knob.
Seat Pivot Control
This control allows operator's seat to be turned to a range of 0 to
90 degrees.
• Pull to pivot seat to the right into work position.
• Release to lock in position.
• Swing operator’s seat to the left to return to drive position.
IMPORTANT: Drive tractor with operator's seat facing front.
Operate rear attachments with seat pivoted to work position.
