Charles RT115 Tier 3 - DRIVE POSITION DESCRIPTIONS

RT115 Tier 3- CONTROLS
DRIVE POSITION DESCRIPTIONS
26 RT115 Tier 3 - CONTROLS
DRIVE POSITION DESCRIPTIONS
DRIVE POSITION DESCRIPTIONS
Parking Brake (orange)
This lever controls parking brake.
• Push to disengage.
• Pull to engage.
Gearbox Control (yellow)
This lever allows operator to
select high or low gearbox setting.
• Move forward to 1 to select
low.
• Move back to 2 to select high.
IMPORTANT: Stop tractor before changing gearbox settings.
c00ic064a.eps
DRIVE POSITION DESCRIPTIONS
Parking Brake (orange)
This lever controls parking brake.
• Push to disengage.
• Pull to engage.
Gearbox Control (yellow)
This lever allows operator to
select high or low gearbox setting.
• Move forward to 1 to select
low.
• Move back to 2 to select high.
IMPORTANT: Stop tractor before changing gearbox settings.
c00ic064a.eps
