RT115 Tier 3- SPECIFICATIONS
A920 BACKHOE
240 RT115 Tier 3 - SPECIFICATIONS
A920 BACKHOE
A920 BACKHOE
DIMENSIONAL U.S. Metric
A Transport height 118 in 3.0 m
C Ground clearance 29 in 740 mm
D Backhoe length, stowed 117 in 2.9 m
F Digging depth, max. 112 in 2.8 m
G Digging depth, 2 ft (0.6 m) flat bottom 109 in 2.7 m
J Operating height, fully raised 156 in 3.9 m
K Loading height 104 in 2.6 m
L Loading reach 78 in 1.9 m
M Reach from swing pivot 158 in 4.0 m
N Swing pivot to centerline axle 57 in 1.4 m
P Bucket rotation 170° 170°
B Stabilizer spread, transport 86 in 2.2 m
E Backhoe or basic unit width 82 in 2.0 m
R Stabilizer spread, operating 121 in 3.0 m
U Leveling angle 10° 10°
A920 BACKHOE
DIMENSIONAL U.S. Metric
A Transport height 118 in 3.0 m
C Ground clearance 29 in 740 mm
D Backhoe length, stowed 117 in 2.9 m
F Digging depth, max. 112 in 2.8 m
G Digging depth, 2 ft (0.6 m) flat bottom 109 in 2.7 m
J Operating height, fully raised 156 in 3.9 m
K Loading height 104 in 2.6 m
L Loading reach 78 in 1.9 m
M Reach from swing pivot 158 in 4.0 m
N Swing pivot to centerline axle 57 in 1.4 m
P Bucket rotation 170° 170°
B Stabilizer spread, transport 86 in 2.2 m
E Backhoe or basic unit width 82 in 2.0 m
R Stabilizer spread, operating 121 in 3.0 m
U Leveling angle 10° 10°
