Charles RT115 Tier 3 - Page 185

RT115 Tier 3 - SERVICE 185
250 HOUR SERVICE
RT115 Tier 3 - SERVICE 185
250 HOUR SERVICE
Check Ground Drive Gearbox Oil
Check oil level at fill (1) every 250 hours. Keep level at raised
horizontal line on gearbox. Add MPL as needed.
Check Differential Oil
Check oil level at fill (1) every 250 hours. Add MPL as needed.
1
2
t03om068a.eps
t03om069a.eps
1
2
Check Ground Drive Gearbox Oil
Check oil level at fill (1) every 250 hours. Keep level at raised
horizontal line on gearbox. Add MPL as needed.
Check Differential Oil
Check oil level at fill (1) every 250 hours. Add MPL as needed.
1
2
t03om068a.eps
t03om069a.eps
1
2
