RT115 Tier 3 - SPECIFICATIONS 237
H1140 SAW
RT115 Tier 3 - SPECIFICATIONS 237
H1140 SAW
Operation U.S. Metric
Maximum breakover angle at full depth 17° 17°
Quantity of cutting teeth on wheel (4.5", 6") 70, 80 70, 80
Counterweight required. Contact your local Ditch Witch dealer for counterweight
requirements.
Power Train
Cutting bit types: Rotating, self-sharpening conical bit with spring retainer.
Carbide cap or carbide insert available.
Cutter wheel type: Steel wheel with 10 bolt-on segments.
Wheel motor: 107 in
3
(1747 cc) radial piston with pair of tapered roller bearings.
Wheel shaft bearing: 3 in (76 mm) flanged cartridge double row, spherical roller
bearing.
Lift provision: Two 4 in (107 mm) hydraulic cylinders.
Gauge shoes: Minimize shock, bearing load, and vibration when cutting and
move spoils away from trench.
Spoil placement: Both sides approximately 12-18 in (305-457 mm) from trench.
