RT115 Tier 3- TRANSPORTATION
TIEDOWN
72 RT115 Tier 3 - TRANSPORTATION
TIEDOWN
Centerline Trencher
Lower trencher to trailer and tie down at attachment frame and
through boom.
Traversing Trencher
Lower trencher to trailer and tie down at attachment frame and
through boom.
IMPORTANT: If trencher is equipped with a trench cleaner,
ensure that trench cleaner shoe is fully up and extra bolt (found
in operator’s manual compartment) is installed in appropriate
hole for additional support.
Centerline Trencher
Lower trencher to trailer and tie down at attachment frame and
through boom.
Traversing Trencher
Lower trencher to trailer and tie down at attachment frame and
through boom.
IMPORTANT: If trencher is equipped with a trench cleaner,
ensure that trench cleaner shoe is fully up and extra bolt (found
in operator’s manual compartment) is installed in appropriate
hole for additional support.
