Charmhigh CHM-T48VB Manual

Charmhigh-V1.0-2016 |
9
All Rights Reserved
6. Technical Parameters
model
CHM-T48VB
PCB area
10mm×10mm～355mm×355mm
X,Y axis stroke
510×460mm
Z axis stroke
15mm
number of nozzle
2
material stack number
ordinary material stack 58, IC material stack up to 14
visual support
dual cameras
Motor drive
Closed-loop servo high voltage drive system（ Ensure the
accuracy of operation）
Z axis back position
detection
Yes
Pull needle auto return
Yes
Leak detection method
Vacuum detection、Visual inspection
LCD Screen
7 inch Industrial LCD screen
Board
Independent research and development of industrial computer
motherboard
System
Embedded Linux system
need external air pump
no(built-in mute air pump)
need external PC
No need
power supply
220V(110V), 50Hz
power
250W
weight
65Kg
volume of packaging
0.41m
3

Charmhigh CHM-T48VB Specifications

General
