危险废弃物
03 Other Aspects
Install the thruster shield
The three snap structures on the thruster shield
should correspond to the thruster conduit
bracket structure one by one, then press down
the shield with slight force, and when the sound
of clatter is heard, the shield is assembled in
place.
4. Thruster Shield Installation
