01 Product Structure
11. Peripheral Interface
（Serial Port: UART1, 2, 3）
12. Battery Twist lock Knob
13. Depth&Temperature Sensor
14. Battery Pull Ring（For battery
disassembling）
15. Tether Socket/Charging Socket（The
pins are prohibited to exposure in
seawater/salt water）
16. Battery Fastener
NOTE：
① UART1/2：3V3TTL;+15V,30W
② UART3：3V3TTL;+18V~+25.2V,50W
③ Ethernet1/2：10/100Mbps,+16V,40W
ROV Structure
01
