Intelect
®
Advanced Vacuum Electrode Module
15
MAINTENANCE
Vacuum Module Cleaning
With the system disconnected from the power source, clean the
vacuum module with a clean, lint free cloth moistened with water and
mild antibacterial soap. If a more sterile cleaning is needed, use a cloth
moistened with an antimicrobial cleaner.
Do not submerse the vacuum module in liquids. Should the vacuum
module accidentally become submersed, contact the dealer or DJO Service
Department immediately. Do not attempt to use a vacuum module that
has been wet inside until inspected and tested by a
Service Technician
certified by DJO.
Cleaning the Vacuum Module
Reservoir Draining
Open the storage bin beneath the
vacuum module to access the Reservoir
Drain Tube. Wearing surgical type
gloves, place a cup with a minimum
capacity of 250 ml (8 fl oz) beneath the
drain tube.
Pull Drain Tube from plug and allow all
liquid to drain into cup.
After draining is complete, reinstall
Drain Tube to plug.
NOTE:
If Drain Tube is not reinstalled onto the
plug the vacuum will not work properly.
Dispose of reservoir contents according
to national, state and local rules and
regulations.
To re-start the Vacuum Module after
draining reservoir, rotate the Vacuum
Intensity Knob counterclockwise until
Vacuum Pump stops then, reset to the
desired vacuum intensity.
