WAVEFORMS (CONTINUED)
GALVANIC: Interrupted
Advice on size and type of electrodes to be used is given in device GUI "treatment guidelines" feature
Galvanic Current is a direct current flowing in one direction only. The current
can be continuous or interrupted.
Pulse Duration 136 µsec
Output Mode Electrodes
Output Intensity 0-40 mA
Polarity Reversal On or Off
With Polarity Reversal On, Polarity will change in the middle of the
treatment time.
Polarity Reversal Ramp 1 sec
Cycle Time Continuous, or User Defined
Treatment Time 1-60 min
Available on Channels 1, 2
Mode Selection CC
IRMS [mA] 0-73.40 mA
DC component Yes
Low Level Galvanic
Advice on size and type of electrodes to be used is given in device GUI "treatment guidelines" feature
Low Level Galvanic Current is a direct current flowing in one direction
only. The intensity is limited to 4.0mA
Output mode Electrodes
Output Intensity 0-4 mA
Dosage 40-80 mA-min
Mode selection CC
Polarity Fixed at positive
DC component Yes
Träbert (Ultrareiz)
The Träbert Current is a monophasic waveform with a phase duration of 2 ms
and a pause of 5 ms resulting in a frequency of approximately 143Hz.
Output Mode Electrodes
Output Intensity 0-80 mA
Polarity Reversal On or Off
With Polarity Reversal On, Polarity will change in the middle of the
treatment time.
Treatment Time 1-60 min
Available on Channels 1, 2
Frequency 143 Hz
Phase Duration 2 ms
Mode Selection CC
IRMS [mA] 0-42.76 mA
DC component Yes
SURGED: monophasic triangular missing
The SURGED: Monophasic Rectangular Current is a series of
rectangular, monophasic pulses. The pulses surge to maximum
power, hold and then decrease before the pause. This
waveform is well suited for muscle strengthening
.
Output Mode Electrodes
Output Intensity 0- 60 MA
Phase Duration 0.2-5.0 ms
Frequency 5-60 Hz
Surges per minute 1-20
Pause 0-57 sec
Treatment Time 1-60 min
Available on Channels 1, 2
Mode Selection CC
IRMS [mA] 0-43.82 mA
DC component Yes
