EXPLODED VIEWS AND SERVICE PARTS LISTS
EN
| Intelect
®
Mobile 2 - Service Manual 75
ITEM N°
Service part n°
Description
Qty
1
14-1043-SP
SERVICE PART M3X8 TORX SCREW x 5
4
2
G16-4151-SP
SERVICE PART MOB2 MAIN BODY WHITE
1
3
14-1044-SP
SERVICE PART M4X8 TORX SCREW x 5
6
4
G16-4461-SP
SERVICE PART MOB2 FRONT LIP W
1
5
G16-1091-SP
SERVICE PART MOB2 FRONT LIP CLAMP B
1
6
14-1043-SP
SERVICE PART M3X8 TORX SCREW x 5
3
7
14-1003-SP
SERVICE PART MOB2 VACUUM RIBBON CABLE
1
8
G16-4141-SP
SERVICE PART MOB2 BASE PLATE BLACK
1
9
G16-0052-SP
SERVICE PART MOB2 CONNECTORS PCBA
1
10
G16-4441-SP
SERVICE PART MOB2 VACUUM CONNECTION COVER BLACK
1
11
G16-4121-SP
SERVICE PART MOB2 RUBBER FOOT FRONT BLACK
1
12
14-1022-SP
SERVICE PART MOB2 FAN
1
13
14-1007-SP
SERVICE PART MOB2 BATTERY TO CONTROL PCBA CABLE
1
14
14-1023-SP
SERVICE PART POWER SUPPLY 24V 100W
1
15
14-1000-SP
SERVICE PART MOB2 INTERNAL USB CABLE
1
16
14-1020-SP
SERVICE PART POWER CONNECTOR
1
17
27151-SP
SERVICE PART SWITCH 20MM BK
1
18
G16-4131-SP
SERVICE PART MOB2 RUBBER FOOT REAR BLACK
1
19
G16-4161-SP
SERVICE PART MOB2 BATTERY COVER BLACK
1
20
14-1047-SP
SERVICE PART M3x12 TORX SCREW x 5
4
