Operation
ILS Command User Manual Rev. 1
Configuration (Settings)
Press the <X> encoder to access the menu.
Press the <Y> encoder to return to the previous menu level or the home screen.
D-Fi Configuration
To select on which D-Fi channel the ILS Command will transmit, do the following:
1. Press the <X> encoder to access the menu.
2. Turn the <X> encoder left or right to select DFI Channel.
3. Press the <X> encoder.
4. Turn the <X> encoder left or right to select from 1–16.
5. Press the <X> encoder.
Back Light
To set the brightness of the button back lights, follow the instructions below.
1. Press the <X> encoder to access the menu.
2. Turn the <X> encoder left or right to select Back Light.
3. Press the <X> encoder.
4. Turn the <X> encoder left or right to increase or decrease the brightness, from 6–100.
5. Press the <X> encoder.
Sound Input
To select the source for sound input, do the following:
1. Press the <X> encoder to access the menu.
2. Turn the <X> encoder left or right to select Sound In.
3. Press the <X> encoder.
4. Turn the <X> encoder left or right to select from MIC (microphone) or AUX (3.5 mm audio in).
5. Press the <X> encoder.
Sound Loss
To select what the ILS Command in sound mode does without sound input, follow the instructions below.
1. Press the <X> encoder to access the menu.
2. Turn the <X> encoder left or right to select Sound Lost.
3. Press the <X> encoder.
4. Turn the <X> encoder left or right to select from HOLD (continues the last instruction), FREEZE
(freezes at current output), or BLACK (blacks out all connected products).
5. Press the <X> encoder.
Par Color
To select the number of colors available to all connected par and wash effects, do the following:
1. Press the <X> encoder to access the menu.
2. Turn the <X> encoder left or right to select Par Color.
3. Press the <X> encoder.
4. Turn the <X> encoder left or right to select from Tri (red, green, and blue), Quad (red, green, blue,
and amber or white), or Hex (red, green, blue, amber, white, and ultraviolet).
5. Press the <X> encoder.
Program Mode
To select between snapping programs and fading programs, follow the instructions below.
1. Press the <X> encoder to access the menu.
2. Turn the <X> encoder left or right to select Program Mode.
3. Press the <X> encoder.
4. Turn the <X> encoder left or right to select from SNAP or FADE.
5. Press the <X> encoder.
Caution: D-Fi 2.4 GHz operation can be interrupted or inhibited by obstructions between
the transmitter and receiver such as structures or people. For best results, keep the line of
sight clear.
