Technical Specifications
ILS Command User Manual Rev. 1
6. Technical Specifications
Dimensions and Weight
Note: Dimensions in inches are rounded.
Power
Thermal
ILS
Ordering
Length Width Height Weight
12.3 in (313 mm) 8.86 in (225 mm) 2.15 in (54.7 mm) 3.6 lb (1.6 kg)
Power Supply Type Range Voltage Selection DC Input
Switching (external) 100 to 240 VAC, 50/60 Hz Auto-ranging 5 V, 1 A
Power I/O U.S./Worldwide UK/Europe
Power input connector USB type C USB type C
Power supply connector USB type A USB type A
Power supply plug NEMA 1-15 (U.S.) Local Plug
Maximum External Temperature Cooling System
104 °F (40 °C) Convection
I/O Connector Operating Frequency Max Unobstructed Distance
3-pin XLR, D-Fi 2.412 to 2.484 GHz 600 ft (183 m)
Product Name Item Code UPC Number
ILS Command 10082103 781462224516
