–14 –
3. Press the or key to perform the calibration adjustment until the value on
thedisplay corresponds to the weight suspended to the material. The adjustment can be
performed in 1 % steps within the range from + 10% to –10%.
4. Press the button to save the determined value.
Guide roller
Guide roller
Measuring
Roller
Material to
be measured
Weight
NOTE: Please note that this is a general value. So determine it separately for each
material characteristic and note it down for later reference. It is not possible to save it
per material characteristic.
To disable calibration adjustment, reset the value to 0% in the Cal. Adjustment menu.
5.8 Peak value
During a measurement cycle, the tension meter automatically calculates the Peak
Minimum and Peak Maximum values. If these values should not be displayed in the bar
graph or in the statistics, disable their display in the main menu. Regardless, the Peak
values will be used and shown always in the software Tension Inspect 3.
FIG. 11
FIG. 12
