Check-line DTS-200 User Manual

– 21 –
Model Tension
Ranges
cN
*Measuring
Head Width
mm
**Factory
Calibration
Matretial 1
Polyamide [PA]
Monofilament
***Material
Thickness
Compensator
for Included
DTS-200 0.2 - 200.0 66 0.12 mm Ø
DTS-500 0.5 - 500.0 66 0.12 + 0.20 mm Ø yes
DTS-1000 10 - 1000 66 0.20 + 0.40 mm Ø yes
DTS-2000 20 - 2000 66 0.40 + 0.70 mm Ø yes
DTS-2500 25 - 2500 116 0.40 + 0.70 mm Ø yes
DTS-4000 40 - 4000 66 0.50 + 0.80 mm Ø yes
DTS-5000 50 - 5000 116 0.60 + 1.20 mm Ø yes
DTS-10K 0.1 - 10.00 daN 116 0.80 + 1.40 mm Ø yes
DTS-20K 0.2 - 20.00 daN 116 1.20 + 1.80 mm Ø yes
DTS-30K 0.3 - 30.00 daN 216 1.40 + 2.00 mm Ø yes
DTS-50K 0.5 - 50.00 daN 216 steel rope 1.5 mm Ø
(7 x 7 x 0.15)
DTS-60K-V1 0.6 - 60.00 daN 280 steel rope 2.0 mm
Ø(7 x 7 x 0.30)
7.2 Available models
International unit of tensile force: 1 cN = 1.02 g = 0.01 N, 1 daN = 1.02 kg = 10.0 N
* Depending on model, either width of lament guide or outer distance between outside guide rollers
** Suitable for 95 % of all applications. PA = Polyamide Monolament. If the material to be measured
differs signicant from the SCHMIDT calibration material in diameter, rigidity, shape, etc., we
recommend calibration using customer supplied material.
Instruments with calibration on customer sample are not adjusted and calibrated on material 1.
*** The DTSB, DTSE, DTSF and DTSL models do not include a material thickness
compensator. They are calibrated only on material 1.
The DTSB is calibrated depending to the range on a textile ribbon or thin tape.
Air humidity 85% RH, max
Power supply LiPo Accumulator (approx. 40 hours continuous use,
chaging time aapro. 3.5 hours
Housing material Die-cast aluminum
Housing dimensions 265mm x 78.5 mm 46 mm (L x W x H)
Weight (net/gross) Up to DTS-50K approx. 875 g / 1550 g
DTS-60K-V1 approx 1040 g / 2700 g
