– 6 –
4.0 TENSION METER SETTINGS
Thumbpiece positions
Pos. 1Pos. 2 Pos. 0
2 = Measurement position
0 = Adjustment position
1 = Threading position (guide rollers in their forward position
Menu settings can be changed with the thumbpiece in
Pos. 0 (Adjustment position). To perform measurements the
thumbpiece must be in the measurement position (Pos. 2).
4.1 Procedure
1. Press the and buttons simultaneously to access the main menu.
2. The and buttons can be used to select the various menu items of the main
menu, the submenus and the settings menus.
3. Press the button to open the selected menu; by pressing the or button you
can close the menu without saving changes.
4. In menus with multi-digit elds (e.g. date) use the and buttons to move
forward and backward between digits.
5. Press the button to save the settings and exit the settings menu or press the
button to exit the current menu without saving.
6. To exit the main menu press the button.
FIG. 5
