5.0 Sighting The Scanner
EXPLOSION HAZARD
Do not connect or disconnect when energized
RISQUE D’EXPLOSION
Ne pas connecter ou débrancher lorsqué énérgé
Proper flame sighting is required for proper flame scanner detection and discrimination. The view through
the sighting port should be the full flame, as illustrated below.
CORRECT INCORRECT
Figure 9: PN: 04005000-SB/MB
