1.0 Important Safety Information
Read All Instructions Before Using Equipment
The instructions in this manual serve as a general guide. It is intended for use by qualified personnel with
knowledge of equipment of this type. It is not intended to cover all possible variations in equipment or to
provide for specific operating problems which may arise.
You are responsible for adhering to all warnings or cautions provided in this manual.
In addition to any general safety measures provided in this manual, you must comply with all national,
state, local, and company safety regulations.
Safety Symbols used in this manual comply with ISO 3864.
THESE SYMBOLS INDICATE POTENTIAL PERSONAL INJURY HAZARDS.
OBEY ALL SAFETY MESSAGES THAT FOLLOW THESE SYMBOLS TO AVOID POSSIBLE INJURY OR DEATH.
Indicates a hazard with a high level of risk, which, if not avoided,
will result in death or severe injury.
Indicates a hazard with a medium level of risk, which, if not
avoided, could result in death or severe injury.
Indicates a hazard with a low level of risk, which, if not avoided,
will result in minor or moderate injury.
