MNL-ISCAN3
REMOTE FILE SELECT
The Remote File Select feature provides a means for selecting one of the configuration files within the
scanner. Single-Burner, “SB,” models have limited programmability, while Multi-Burner, “MB” models
have a high degree of programmability, as outlined in the table below.
2.2 Thermal Protection
The iScan®3 Flame Scanner has redundant safety features for exposure above the maximum temperature
rating. The modes of operation are described below:
Mode
Internal Temperature (T
INT
)
4-20 Output Setting
Indicator Light Setting
Relay Operation
Normal
T
INT
≤ 95°C
Normal (4-20 mA)
Normal
Normal
Warning
95°C < T
INT
< 100°C
3mA steady
Alternate left half yellow 0.5s
/ right half yellow 0.5s
Normal
Fault
100°C < T
INT
≤ 105°C
2mA steady
Blink yellow 0.5s on 0.5s off
Relays Open and will not
Close
Disable
T
INT
> 105°C
1mA steady
Yellow Solid
Relays Permanently Open
and will not Close
Scanner PN
USER PROGRAMMABLE FEATURES (with iScan Software)
4-20 mA
Signal
Mapping
4-20 mA
Calibrate
4-20
mA
Gain
Secondary Relay:
Redundant Flame
N.O. or N.C. -or-
Fault N.O. or N.C.
Detection
Settings:
Gain, Freq,
Threshold
Multiple Files
Select
(Max of 4)
Response Times
(Flame On/
Flame Off)
04005000-SB
YES
YES
YES
YES
NO
NO
NO
04005000-MB
YES
YES
YES
YES
YES
YES
YES
