TOLERANCE NOTES
FABRICATED TOLERANCES
≥ 2 ft (610 mm) ± 0.250 in (6.4 mm)
< 2ft (610 mm) ± 0.125 in (3.2 mm)
MACHINED TOLERANCES
± 0.050 DECIMAL DIM (1 PLACE)
± 0.010 DECIMAL DIM (2 PLACES)
± 0.005 DECIMAL DIM (3 PLACES)
MNL-ISCAN3
Purge Air
NOTE 1
Flow
Pressure
5 scfm (8.5 Nm
3
/hr)
5” w.c. (13 mbar)
ROL - Ring of Light
Status Indicator
Color Coded Status
Field of View
6 Degrees
Optics
Quartz Lens
Sensor Type
Solid-State
Sensor Range
300 nm to 750 nm
Communication
USB/RS485: up to 127 scanners, overall length up to a distance of 4000 Ft.
(1200 M).
Temperature
-40°C to 80°C
Humidity
0 to 100% Relative Humidity, Condensing
Input Power
NOTE 2
24 VDC, +10%/-15%, 5.28 W (220 mA MAX)
Relay Contacts
NOTE 3
Primary Relay with Normally Open and Normally Closed Voltage Free
Contacts (i.e., NO contact closes when a flame is detected, NC opens when a
flame is detected)
Secondary Relay with Voltage-Free Contacts
(configurable as NO Flame Relay or Fault Relay configurable as NO or NC
contacts)
0.250A @ 125 VAC Resistive Load
1.0 A @ 24 VDC Resistive Load
0.5 A @ 48 VDC Resistive Load
Signal Output
NOTES 4,5
Output #1, 4–20 mA, Flame Signal
Output # 2, 4-20 mA, Selectable as Gain or Internal Temperature
Maximum Current Loop Resistance = 750 ohms
FDORT (FLAME ON)
Configurable from 1-4 seconds in 1-second increments
FDRT (FLAME OFF)
Configurable from 1-4 seconds in 1-second increments
MFRRT
Configurable from 1-6 seconds in 1-second increments
Safety Integrity Level
(SIL3) Data
PFD
AVG
= 938.369 X 10
-6
λ
SU
= 1.14 X 10
-6
λ
DD
= 2.1705 X 10
-6
λ
DU
= 0.0219 X 10
-6
SFF = 99.1%
Proof Test Interval
time = 1 year (8760 Hrs)
NOTE 6
