Default Configuration (Settings)
As part of setup in iScanSoftware, each scanner is assigned unique addresses.
Flame Detector On Response Time (FDORT)
2 seconds nominal
Flame Detector Response Time (FDRT)
1 second nominal
Marginal Flame Failure Response Time (MFFRT)
2 seconds nominal
Gain Configuration
Manual
Gain Channel
High
Signal Gain
3.5
Flame Flicker Frequency
26 Hz
Flame Flicker Bandwidth
12 Hz
Flame Flicker Threshold
-45 dB
Mains Filter
Enabled
Rail Filter
Enabled
Solar Filter
Enabled
Flame Filter
Enabled
The following settings apply to the overall scanner and not to an individual scanner file:
Communications Address
COMM 1
NOTE 1
Active File
A
Remote File Select
Disabled
Multiple Fuels
Disabled
4 To 20 mA Gain
1 mA/dB above
threshold
