MNL-ISCAN3, REVB INSTALLATION & OPERATION MANUAL Page 17 of 25
DCO #12743 For Technical Support Call: +1.866.821.5504 Schedule Document
FIGURE B: SEAT THE CONNECTOR AND SEAT THE LOCKNUT AGAINST THE CONNECTOR BARREL.
FIGURE C: TIGHTEN LOCKING NUT AGAINST CONNECTOR BARREL.
EXPLOSION HAZARD
DO NOT CONNECT OR DISCONNECT WHEN ENERGIZED
TENSION DANGEREUSE
NE PAS CONNECTER OU DÉBRANCHER LORSQUE ÉNERGÉ
