CHERUBINI Wave RX - Deleting the Limit Switch Positions; Deleting the Closing Limit Switch; Deleting the Opening Limit Switch; Total Deleting of the Limit Switches

32
TOTAL DELETING OF THE LIMIT SWITCHES
Tn: Already programmed remote control
Tn Tn Tn (4 sec)
DELETING THE LIMIT SWITCH POSITIONS
DELETING THE OPENING LIMIT SWITCH
To delete only the opening limit switch perform the following steps and proceed with
“SETTING THE OPENING LIMIT SWITCH”.
Tn: Already programmed remote control
Tn Tn Tn (2 sec)
DELETING THE CLOSING LIMIT SWITCH
To delete only the closing limit switch perform the following steps and proceed with
“SETTING THE CLOSING LIMIT SWITCH”.
Tn: Already programmed remote control
Tn Tn Tn (2 sec)
NB: by deleting the limit switches, the setting of the closing force is maintained (see
p. 34).
+
B C
+
B C
+
A B
+
B C
+
B C
C
+
B C
+
B C
+
B C
