Air flow distribution knob
This knob is ued to select the direction of
air flow.
This knob has the following five
positions:
Head
Head and foot
Foot
Foot defrosting
Defrosting
“Head” position ( )
The air flows out from the central and
side vents.
“Head and foot” position ( )
The air flows out from the central vents
and the lower discharge ports of the front
seats..
“Foot” position ( )
The air mainly flows out from the lower
discharge ports of front seats.
“Foot defrosting” position ( )
The air flows out from the lower
discharge ports of front seats, windscreen
defroster vents and front window
defroster vents
“Defrosting” position ( )
The air flows out via the windscreen
