The jack is placed in front of spare
wheel stored in luggage boot.
Jack lift point
The jack is available to bear the
specified position of the bottom of car
as shown in the figure only. The groove
position of the jack supports the raised
position of the bottom of car.
The jack lift point shall be fully close
to wheel to be repaired.
The jack lift position of front wheel
(the black block as showin in the
figure)
The jack lift position of rear wheel (the
black block as showin in the figure)
Remove the wheel
1. Make sure that the vehicle parks
on a reliable level ground and the
front wheel points to the dead
ahead.
2. Turn off the ignition switch.
3. Please select the P position, in
case of the vehicle equipped with
the automatic transmission.
4. Please let passengers leave the
vehicle.
5. Use the appropriate wheel
stopper to secure the vehicle to
avoid tumbling or slipping, if
necessary.
6. Insert a flat screwdriver into the
