Chery S18D Service Manual
2.4. Remove the two evaporator nuts fixed onto
sheet metal with 10# socket wrench.
2.5. Use clamp pliers to remove the inlet/outlet
water pipes of the evaporator and pull out the
pipes.
Note: Coolant will flow out from the water pipe,
pay attention to recycle the coolant.
2.6. Loosen off the 3 fixing nuts that fix the
evaporator assembly on the sheet metal with
10# socket wrench (See the following figures
for detailed positions).
49
