Chery S18D Service Manual
3.1.1. Remove the pull rod from the upper lock
body.
3.1.2. Disconnect the connector on upper lock
body.
3.1.3. Remove the screws on the upper lock
with cross ratchet wrench.
Installation torque: 12±1N.m
3.1.4. Remove the luggage boot lock.
3.2. Installation Procedure
The installation procedures are reverse to those
for removal.
Installation precautions: check if the lock cylinder
has deformation, if the riveted joint is in position, if
the luggage boot lock body sleeve is in good
condition, if the lock tongue can open and shut
freely.
4. Removal of Luggage Boot Lock Cylinder
4.1. Removal Procedure
4
