Chery S18D Service Manual
6.1.3. Align with the slot opening on one end of
control arm and remove the control arm.
6.2. Installation Procedure
The installation procedures are reverse to those
for removal.
7. Removal and Installation of Int./Ext.Air Door Motor & Related Mechanism
7.1. Removal Procedure
7.1.1. Pull out the motor connector.
7.1.2. Remove the fixing screws of control
motor and remove the motor.
7.2. Installation Procedure
The installation procedures are reverse to those
for removal.
8. Removal and Installation of Evaporator
8.1. Removal Procedure
54
