Chevrolet Volt Owner Manual - 2012
Vehicle Care 10-35
Mini Fuses Usage
4
Ignition Coils/
Injectors
5 Not Used
6a Empty
6b Not Used
7 Empty
8 Empty
9 Heated Mirrors
10
Air Conditioning
Control Module
11
Traction Power
Inverter
Module – Battery
12 Not Used
13
Cabin Heater Pump
and Valve
14 Not Used
Mini Fuses Usage
15
Traction Power
Inverter Module and
Transmission
Control
Module – Battery
17
Engine Control
Module – Battery
22
Left High‐Beam
Headlamp
24 Empty
25 Empty
26 Not Used
31 Not Used
32
Run/
Crank – Sensing
Diagnostic Module
(SDM), Instrument
Cluster, Passenger
Airbag Display,
Automatic Dimming
Inside Rearview
Mirror (If Equipped)
Mini Fuses Usage
33
Run/Crank for
Vehicle Integration
Control Module
34
Vehicle Integration
Control
Module – Battery
35 Not Used
36
Power Electronics
Coolant Pump
37
Cabin Heater
Control Module
38
Rechargeable
Energy Storage
System (High
Voltage Battery)
Coolant Pump
