Mini Fuses Usage
39
Rechargeable
Energy Storage
System (High
Voltage Battery)
Control Module
40
Front Windshield
Washer
41
Right High‐Beam
Headlamp
46 Empty
47 Empty
49 Empty
50
Run/Crank – Rear
Vision Camera,
Accessory Power
Module
Mini Fuses Usage
51
Run/Crank for ABS/
Rechargeable
Energy Storage
System (High
Voltage Battery)
52
Engine Control
Module/
Transmission
Control
Module – Run/Crank
53
Traction Power
Inverter
Module – Run/Crank
54
Run/Crank – Fuel
System Control
Module, Air
Conditioning Control
Module, On Board
Charger
J‐Case
Fuses
Usage
16
AIR Solenoid
(PZEV Only)
18 Empty
19
Power
Window – Front
20 Empty
21
Antilock Brake
System Electronic
Control Unit
23 Charge Port Door
27
AIR Pump
(PZEV Only)
