Vehicle Care 10-37
J‐Case
Fuses
Usage
28 Empty
29 Empty
30
Antilock Brake
System Motor
42 Cooling Fan – Right
43 Front Wipers
44 Charger
45 Empty
48 Cooling Fan – Left
Mini Relays Usage
3 Powertrain
4 Heated Mirrors
7 Empty
9
AIR Pump
(PZEV Only)
11 Empty
12 Empty
13 Empty
14 Run/Crank
Micro
Relays
Usage
1 Empty
2
AIR Solenoid
(PZEV Only)
6 Empty
8 Empty
10 Empty
Ultra Micro
Relays
Usage
5 Charge Port Door
