R410A50Hz Universal Outdoor Series TechnicalManual Outdoor unit
148
GD Chigo Heating & Ventilation Equipment Co., Ltd.
15
Connecting pipe for low-valve
1
16
Refrigerate-capillary
1
17
Exhaust pipe assy
1
17.1
High-pressure switch
1
17.2
Instalation tube for probe
1
18
The air-returning pipe
1
18.1
Low-pressure switch
1
18.2
Base borad for valve assy
1
19
Base borad for valve
1
19.1
Stop valve
1
19.2
Stop valve
1
20
Compressor assy C-SB303H8A
1
21
Chassis(No.43 of Commercial)
1
22
Maintenance panel
1
23
Median septum
1
