Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
30
GD Chigo Heating & Ventilation Equipment Co., Ltd.
6.4CCA-24HR1,CCA-24CR1
MODEL
CCA-24HR1
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25ºC
30ºC
35ºC
40ºC
43ºC
21ºC D 15ºC W
Total capacity kW
6.67
6.60
6.54
6.44
5.78
4.91
Input kW.
2.28
2.33
2.38
2.45
2.60
2.71
24ºC D 17ºC W
Total capacity kW
7.00
6.93
6.86
6.76
6.07
5.16
Input kW.
2.33
2.38
2.43
2.50
2.65
2.76
27ºC D 19ºC W
Total capacity kW
7.35
7.28
7.21
7.10
6.37
5.42
Input kW.
2.38
2.43
2.48
2.55
2.71
2.82
29ºC D 19ºC W
Total capacity kW
7.65
7.57
7.50
7.38
6.63
5.63
Input kW.
2.43
2.48
2.53
2.60
2.76
2.87
32ºC D 23ºC W
Total capacity kW
7.95
7.87
7.79
7.68
6.89
5.86
Input kW.
2.48
2.53
2.57
2.65
2.82
2.93
6.5 CCA-36HR1,CCA-36CR1
MODEL
CCA-36HR1
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25ºC
30ºC
35ºC
40ºC
43ºC
21ºC D 15ºC W
Total capacity kW
9.86
9.77
9.67
9.53
8.55
7.27
Input kW.
3.55
3.62
3.69
3.81
4.04
4.20
24ºC D 17ºC W
Total capacity kW
10.36
10.25
10.15
10.00
8.98
7.63
Input kW.
3.62
3.69
3.77
3.88
4.12
4.29
27ºC D 19ºC W
Total capacity kW
10.88
10.76
10.66
10.50
9.43
8.01
Input kW.
3.69
3.77
3.85
3.96
4.20
4.37
29ºC D 19ºC W
Total capacity kW
11.31
11.20
11.09
10.92
9.80
8.33
Input kW.
3.77
3.85
3.92
4.04
4.29
4.46
32ºC D 23ºC W
Total capacity kW
11.76
11.64
11.53
11.36
10.19
8.66
Input kW.
3.85
3.92
4.00
4.12
4.37
4.55
6.6 CCA-48HR1,CCA-48CR1
MODEL
CCA-48HR1
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25ºC
30ºC
35ºC
40ºC
43ºC
21ºC D
15ºC W
Total capacity kW
13.15
13.02
12.89
12.70
11.40
9.69
Input kW.
4.64
4.74
4.83
4.98
5.28
5.50
24ºC D
17ºC W
Total capacity kW
13.81
13.67
13.53
13.33
11.97
10.17
Input kW.
4.74
4.83
4.93
5.08
5.39
5.61
27ºC D
19ºC W
Total capacity kW
14.50
14.35
14.21
14.00
12.57
10.68
Input kW.
4.83
4.93
5.03
5.18
5.50
5.72
29ºC D
19ºC W
Total capacity kW
15.08
14.93
14.78
14.56
13.07
11.11
Input kW.
4.93
5.03
5.13
5.28
5.61
5.83
32ºC D
23ºC W
Total capacity kW
15.68
15.52
15.37
15.14
13.59
11.55
Input kW.
5.03
5.13
5.23
5.39
5.72
5.95

Chigo CCB-12HR1 Specifications

General

Brand	Chigo
Model	CCB-12HR1
Category	Air Conditioner
Language	English
