Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
31
GD Chigo Heating & Ventilation Equipment Co., Ltd.
6.7 CCA-60HR1,CCA-60CR1
MODEL
CCA-60HR1
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25ºC
30ºC
35ºC
40ºC
43ºC
21ºC D 15ºC W
Total capacity kW
15.03
14.88
14.73
14.51
13.03
11.07
Input kW.
5.27
5.38
5.48
5.65
5.99
6.24
24ºC D 17ºC W
Total capacity kW
15.78
15.62
15.46
15.23
13.68
11.62
Input kW.
5.38
5.48
5.60
5.77
6.12
6.37
27ºC D 19ºC W
Total capacity kW
16.57
16.40
16.24
16.00
14.37
12.21
Input kW.
5.48
5.60
5.71
5.88
6.24
6.49
29ºC D 19ºC W
Total capacity kW
17.23
17.06
16.89
16.64
14.94
12.70
Input kW.
5.60
5.71
5.82
5.99
6.37
6.62
32ºC D 23ºC W
Total capacity kW
17.92
17.74
17.57
17.30
15.53
13.20
Input kW.
5.71
5.82
5.94
6.12
6.49
6.75
Heating
6.8 CCB-12HR1
MODEL
CCB-12HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC DB
18ºCWB
12ºC DB
11ºCWB
7ºC DB
6ºC WB
4ºC DB
3ºC WB
0ºC DB
-1ºCWB
-5ºC DB
-6ºCWB
-7ºC DB
-8ºCWB
15ºC
Capacity kW
4.34
4.25
4.19
3.99
3.85
3.55
3.36
Input kW.
1.23
1.25
1.28
1.29
1.30
1.31
1.32
18ºC
Capacity kW
4.13
4.05
3.99
3.80
3.67
3.38
3.20
Input kW.
1.25
1.28
1.30
1.32
1.32
1.34
1.34
20ºC
Capacity kW
3.94
3.86
3.80
3.62
3.50
3.22
3.05
Input kW.
1.38
1.31
1.33
1.34
1.35
1.36
1.37
22ºC
Capacity kW
3.75
3.67
3.62
3.45
3.33
3.06
2.90
Input kW.
1.30
1.33
1.36
1.37
1.38
1.39
1.40
27ºC
Capacity kW
3.57
3.50
3.45
3.28
3.17
2.92
2.77
Input kW.
1.33
1.36
1.38
1.40
1.41
1.42
1.43
6.9 CCB-18HR1
MODEL
CCB-18HR1
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC DB
18ºC WB
12ºC DB
11ºC WB
7ºC DB
6ºC WB
4ºC DB
3ºC WB
0ºC DB
-1ºC WB
-5ºC DB
-6ºC WB
-7ºC DB
-8ºC WB
15ºC
Capacity kW
6.69
6.56
6.46
6.15
5.94
5.47
5.18
Input kW.
1.68
1.72
1.75
1.77
1.78
1.79
1.80
18ºC
Capacity kW
6.37
6.25
6.15
5.86
5.66
5.21
4.93
Input kW.
1.71
1.75
1.79
1.80
1.81
1.83
1.84
20ºC
Capacity kW
6.07
5.95
5.86
5.58
5.39
4.96
4.70
Input kW.
1.88
1.79
1.82
1.84
1.85
1.86
1.88
22ºC
Capacity kW
5.78
5.66
5.58
5.31
5.13
4.72
4.48
Input kW.
1.78
1.82
1.86
1.88
1.89
1.90
1.91
27ºC
Capacity kW
5.51
5.39
5.32
5.06
4.89
4.50
4.26
Input kW.
1.82
1.86
1.89
1.91
1.92
1.94
1.95
