R410A50Hz Universal Outdoor Series Technical Manual Duct Type Indoor Unit
53
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Stuffing
Quantity(20'/40'/40'
HQ)
set 115/250/320 115/250/320 75/165/189 90/190/255 90/190/255
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent ref. Piping: 5m(horizontal)
2.Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. Piping: 5m(horizontal)
3.Actual noise level may differ, depending on the room structure, etc, since these noise values are from an
anechoic room.
Model
CTB-24HR
1
CTB-24CR
1
CTB-36HR1 CTB-36CR1 CTB-48HR1 CTB-48CR1
Indoor power
supply
V/Ph
/Hz
220~240V/
1Ph/50Hz
220~240V/
1Ph/50Hz
220~240V/1
Ph/50Hz
220~240V/1
Ph/50Hz
220~240V/1
Ph/50Hz
220~240V/1
Ph/50Hz
Cooli
ng
Capacit
y
Btu/
h
24000 24000 36000 36000 48000 48000
KW
7.1
7.1
10.5
10.5
14
14
Input
W
250
250
300
300
340
340
Rated
current
A 1.1 1.1 1.4 1.4 1.6 1.6
EER
W/W
2.68
2.68
2.56
2.56
2.62
2.62
Heati
ng
Capacit
y
Btu/
h
26000 26000 39000 39000 52000 52000
KW
7.7
7.7
11.5
11.5
15.2
15.2
Input
W
250
250
300
300
340
340
Rated
current
A 1.1 1.1 1.4 1.4 1.6 1.6
COP
W/W
3.28
3.28
2.95
2.95
2.79
2.79
Indo
or
fan
moto
r
Model
YSK110-9
0F-4P3H1
05
YSK110-9
0F-4P3H1
05
YDK110-75F
-4P3H105L-1
+YSK120-15
0F-4P3H105
-1
YDK110-75F
-4P3H105L-1
+YSK120-15
0F-4P3H105
-1
YDK110-75
F-4P3H105
L
+YSK120-1
50F-4P3H1
05
YDK110-75
F-4P3H105
L
+YSK120-1
50F-4P3H1
05
Input
W
250
250
300
300
340
340
Capacit
or
μF 5 5 3+5 3+5 3+5 3+5
Speed(
Hi/Me/L
o)
r/min
1100/940/8
50/800
1100/940/8
50/800
1310/1170/1
090/1040
+1300/1200/
1110/1060
1310/1170/1
090/1040
+1300/1200/
1110/1060
1340/1270/
1200/1130
+1340/1240
/1140/1040
1340/1270/
1200/1130
+1340/1240
/1140/1040
Indo
or
coil
Number of
rows
3 3 3 3 3 3
Fin
spacing
mm 1.7 1.7 1.7 1.7 1.8 1.8
Fin type
Hydrophili
c
Hydrophili
c
Hydrophilic Hydrophilic Hydrophilic Hydrophilic
Number of
circuits
6 6 6 6 5 5
Indoor air
flow(High
speed)
m
3
/h 1200 1200 1900 1900 2000 2000
Static Pressure
Pa
30-70
30-70
30-70
30-70
30-70
30-70
Indoor noise
level
dB(A
)
40～48 40～48 40～50 40～50 40～50 40～50
