Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual Duct Type Indoor Unit
55
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Indoor
fan
motor
Model
YDK110-75F-4P3H1
05L
+YSK120-150F-4P3
H105
YDK110-75F-4P3H1
05L
+YSK120-150F-4P3
H105
YSK139-300F-4P3
H95
YSK139-300F-4P3
H95
Input
W
340
340
500
500
Capacitor μF 3+5 3+5 15 15
Speed(Hi/Me/
Lo)
r/min
1340/1270/1200/113
0
+1340/1240/1140/10
40
1340/1270/1200/113
0
+1340/1240/1140/10
40
1050/830/720 1050/830/720
Indoor
coil
Number of rows 3 3 3 3
Fin spacing mm 1.8 1.8 1.6 1.6
Fin type
Hydrophilic
Hydrophilic
Hydrophilic
Hydrophilic
Number of circuits
5
5
6
6
Indoor air flow(High
speed)
m
3
/h 2000 2000 2300 2300
Static Pressure
Pa
30-70
30-70
120
120
Indoor noise level
dB(A)
40～50 40～50 44～52 44～52
Indoor
unit
Dimension
Body(m
m)
1425×643×260 1425×643×260 1175×610×370 1175×610×370
(W*H*D)
Packing
Body(m
m)
1490×720×325 1490×720×325 1245×655×445 1245×655×445
(W*H*D)
Net/Gross
weight
Body(Kg
)
44/48 44/48 45/49 45/49
Max
pressure
MPa 4.5 4.5 4 4
Refrigerant type R410A R410A R410A R410A
Refrigera
nt piping
Liquid
side/Gas side
mm Φ9.52/Φ19.05 Φ9.52/Φ19.05 Φ9.52/Φ19.05 Φ9.52/Φ19.05
Drainage pipe mm 25 25 25 25
Controller Standard for wired controller(remote controller for option)
Operation temp °C 16～32 16～32 16～32 16～32
Ambient temp °C -7～50 -7～50 -7～50 -7～50
Application area m
2
60~105 60~105 55~95 60~105
Stuffing
Quantity(20'/40'/40'HQ)
set 75/165/168 75/165/168 75/165/168 75/165/168
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent ref. Piping: 5m(horizontal)
2.Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. Piping: 5m(horizontal)
3.Actual noise level may differ, depending on the room structure, etc, since these noise values are from an
anechoic room.
