Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual Duct Type Indoor Unit
85
GD Chigo Heating & Ventilation Equipment Co., Ltd.
8
the top cover assy of air retrun box
1
8.1
the top cover of air retrun box
1
8.2
hanger
2
9
the left side plate assy of air return box
1
10
the motor assy
1
10.1
the motor fixed plate assy
1
10.2
the motor supporting
1
10.3
the connected plate of motor supporting
1
10.4
the volute
2
10.5
the right cover for motor
1
10.6
the left cover for motor
1
10.7
the motor
1
11
E-box
1
11.1
the bottom plate of E-box
1
11.2
the cover of E-box
1
11.3
the seat of PCB
1
11.4
PCB
1
11.5
the resistance
1
11.6
transformer
1
11.7
the resistance of motor connecting
1
12
the fixed plate component
1
13
the cover assy for output pipe
1
14
the left side plate component
1
15
the bottom plate of air return box
1
