Chigo CCB-18HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual Floor & Ceiling Indoor Unit
114
GD Chigo Heating & Ventilation Equipment Co., Ltd.
9.14
Louver holder
2
29.2
distributor
1
9.15
Guard vane
12
30
air inlet header pipe assembly of evaporator
1
10
Chassis
1
30.1
Single Connector
1
11
left retaining plate
2
31
left mounting plate of evaporator
1
12
right retaining plate
2
32
weld assembly of Water drain pan
1
13
filter snap-gauge
2
32.1
water outlet rubber cover
1
14
air inlet grille
2
33
remote controller
1
15
Filter
4
10.Accessories
Installation fittings
Name
Shape
Quantity
Hanging arm
2
Controller
Remote controller
1
Remote controller holder
(optional)
1
Wire controller (optional)
1
Mounting screw
(ST2.9×10-C-H)
2
Alkaline dry batteries (AM4)
2
Others
Installation & operation
instruction manual
1

Chigo CCB-18HR1 Specifications

General

Brand	Chigo
Model	CCB-18HR1
Category	Air Conditioner
Language	English
