R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
11
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Model
CCA-36HR1
CCA-48HR1
CCA-60HR1
Indoor power supply
V/Ph/Hz
220~240/1/50
220~240/1/50
220~240/1/50
Cooling
Capacity
Btu/h
36000
48000
60000
KW
10.5
14
16
Input
W
160
180
180
Rated current
A
0.73
0.82
0.82
EER
W/W
2.71
2.70
2.72
Heating
Capacity
Btu/h
39600
52800
66000
KW
11.6
15.4
17.6
Input
W
160
180
180
Rated current
A
0.73
0.82
0.82
COP
W/W
3.31
3.14
2.82
Indoor fan
motor
Model
YDK-75T-6
YDK-75T-6P3-1
YDK-75T-6P3-1
Input
W
160
180
180
Capacitor
μF
4
5
5
Speed(Hi/Med/Lo)
r/min
760/680/580
850/750/650
850/750/650
Indoor coil
Number of rows
2
2
2
Tube pitch x row pitch
mm
21×12.7
21×12.7
20×17.32
Fin spacing
mm
1.45
1.45
1.5
Fin type
Hydrophilic
Hydrophilic
Hydrophilic
Tube outside dia. and
type
mm
Ф7
Ф7
Ф7.94
inner grooved
inner grooved
inner grooved
Coil size(W×H×D)
mm
1791×252×25.4
2005×252×25.4
1929×252×34.64
Number of circuits
8
8
8
Indoor air flow(Hi/Med/Lo)
m
3
/h
1600/1300/1100
1900/1550/1300
1900/1550/1300
Indoor noise level(Hi/Med/Lo)
dB(A)
44/41/38
46/43/40
46/43/40
Indoor unit
Dimension(W×H×D)
Body(mm)
840×285×840
840×285×840
840×285×840
Panel(mm)
950×50×950
950×50×950
950×50×950
Packing(W×H×D)
Body(mm)
920×375×920
920×375×920
920×375×920
Panel(mm)
1030×105×1030
1030×105×1030
1030×105×1030
Net/Gross weight
Body(Kg)
31/35
31/35
31/35
Panel(Kg)
5/7
5/7
5/7
Refrigerant type
R410A
R410A
R410A
Refrigerant
piping
Liquid side/Gas side
mm
Φ9.52/Φ19.05
Φ9.52/Φ19.05
Φ9.52/Φ19.05
Drainage pipe
mm
25
25
25
Connection
wiring
Power Supply
From indoor unit
From indoor unit
From indoor unit
Indoor power wiring
mm
2
1.0
1.0
1.0
Signal wiring
mm
2
0.75
0.75
0.75
Controller
Standard for remote controller(wired controller for option)
Operation temp
°C
16～32
16～32
16～32
Ambient temp
°C
-7～43
-7～43
-7～43
Application area
m
2
40-70
55~95
60~105
Stuffing Quantity(20'/40'/40'HQ)
65/130/150
65/130/150
65/130/150
Notes: 1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent ref. Piping: 7.5m(horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. Piping: 7.5m(horizontal)
3. Actual noise level may differ, depending on the room structure, etc, since these noise values are from an anechoic room.
