R410A50Hz Universal Outdoor Series Technical Manual Outdoor unit
141
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Qty
No.
Part Name
Qty
1
Cover
1
9.3
Discharge temp sensor
1
2
Rear net
1
10
4-Ways valve assy
1
3
E-parts assy
1
10.1
4-Ways valve assy
1
3.1
Fan motor capacitor
1
10.2
Control wire for 4-Ways valve
1
3.2
Contactor
1
11
Compressor
1
3.3
Terminal
1
12
Suction pipe for compressor
1
3.4
Terminal
1
13
Vapor-liquid seperator
1
3.5
Cover for E-parts
1
14
Maintenance board assy
1
3.6
Patch board
1
14.1
Maintenance board
1
3.7
Protection cap
2
14.2
Handle
1
3.8
Groove clamp 4
1
15
Front panel assy
1
4
Right clapboard assy
1
15.1
Panel
1
4.1
Right clapboard
1
15.2
Top net
1
4.2
handle
1
16
Propeller fan
1
5
Valve holder assy
1
17
Fan motor
1
5.1
Valve holder
1
18
Holder for fan motor
1
5.2
Cut-off valve
1
19
Separating board
1
5.3
Cut-off valve DN16
1
20
Chassis
1
6
Pre-welding assy for throttle capillary
1
21
Left clapboard
1
7
Discharge pipe B for compressor
1
22
Condenser assy
1
8
Pre-welding assy for compressor
suction pipe B
1
22.1
Condenser
1
8.1
Suction pipe B for compressor
1
22.2
condensor collecting pipe Pre-welding
assy
1
8.2
Low-pressure swicth
1
22.3
distributing capillary Pre-welding
assy
1
9
Pre-welding assy for discharge pipe A
1
22.4
Temp sensor
1
9.1
Discharge pipe A for compressor
1
23
Refrigerant R410a
2.1kg
9.2
High-pressure switch
1
