R410A50Hz Universal Outdoor Series Technical Manual Outdoor unit
143
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No
.
Part Name
Quantit
y
No.
Part Name
Quanti
ty
1
Cover
1
17.1
Fan motor support
1
2
Rear clapboard
1
17.2
Joint board for fan motor support
1
3
Rear clapboard for valve
1
18
Chassis weld parts
1
4
High-pressure valve joint tube assy
1
19
Compressor foot cover
1
5
Discharge pipe assy
1
20
Separating board
1
5.1
Discharge pipe
1
21
Valve holder
1
5.2
High-pressure swicth
1
21.1
Valve holder
1
5.3
Discharge temp sensor
1
21.2
Cut-off valve DN8
1
6
4-Way valve assy
1
21.3
Cut-off valve DN16
1
6.1
4-Way valve assy
1
22
column
1
6.2
Control wire for 4-Ways valve
1
23
Condenser assy
1
7
Suction pipe assy
1
23.1
Condenser
1
7.1
Suction pipe
1
23.2
Condensor collecting pipe assy
1
7.2
Low-pressure swicth
1
23.3
Distributing capillary assy
1
8
Vapor-liquid seperator
1
23.4
Temp sensor
1
9
Compressor
1
24
E-parts assy
1
10
Right clapboard
1
24.1
Installation board for E-parts
1
11
Right clapboard for valve
1
24.2
Sequence protector
1
12
Top net
2
24.3
Contactor
1
13
Handle
3
24.4
Fan motor capacitor
1
14
Front panel
1
24.5
Terminal
1
15
Propeller fan
2
24.6
Groove clamp
2
16
Asynchronous motor
2
25
Plastic rear net
1
17
Fan motor support
1
26
Refrigerant R410a
3.6kg
