R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
30
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Quantit
y
No.
Part Name
Quantity
1
Warning panel
1
8.3.4
Installation tube for probe
1
2
Circuit diagram panel
1
9
Water pump
1
3
Small wind inlet guide
1
10
Liquid-level sensor
1
4
E-parts components
1
11
Water pump fan motor holder
1
4.1
E-parts box welding assy
1
12
Underlay for water pump support
3
4.2
No.3 groove clamp
1
13
Upper foam
1
4.3
(ROHS)Transformer
1
14
Centrifugal fan
1
4.4
Fan motor capacitor
1
15
Hanger
4
4.5
Terminal (DJ-75W-3PA)
1
16
Rear brattice
1
4.6
Terminal (DJ-75W-5PA)
1
17
Fan motor for indoor unit
(YDK-55T-6)
1
4.7
Electric control board for indoor
unit
1
17.1
Fan motor foot underlay
1
4.8
E-parts box
1
18
Chassis assy
1
5
Water pan assy
1
19
Right clapboard
1
6
Auxiliary fixing board for
evaporator
2
20
Front brattice
1
7
Main fixing board assy
1
21
Discharge pipe joint
1
7.1
Main fixing board for evaporator
1
22
Side maintenance board for water
pump
1
8
Evaporator components
1
23
Lower clamp
1
8.1
Rubber insulating pipe
1
24
Upper clamp
1
8.2
Insulating pipe
1
25
Valve panel
1
8.3
Welding parts for evaporator
1
26
Wire board
2
8.3.1
Collecting pipe assy for evaporator
1
27
Left clapboard
1
8.3.2
Distributing pipe assy for
evaporator
1
28
Water outlet pipe
1
8.3.3
Evaporator
1
